Single Shaft Shredder Machine
单轴碎纸机是一种高效的废物处理设备，设计用于快速、彻底地粉碎各种材料，包括塑料、纸张、纺织品和其他类型的废物。这种碎纸机配备了一个功能强大的单旋转切割轴，利用高速旋转和专门设计的刀片将废物有效地切割成易于处理的小块，从而大大减少了废物量。.
由于其独特的设计和创新的工作原理，单轴撕碎机是废物管理和回收行业的理想解决方案。它不仅能减少废物，提高处理效率，还能帮助企业更有效地管理废物，同时最大限度地减少对环境的影响。.
产品详情
单轴碎纸机减速机在有效地将动力从电机传输到切割轴方面起着至关重要的作用。它设计紧凑，采用高强度材料，可承受重负荷运行。精密加工的齿轮可确保平稳啮合，最大限度地减少运行过程中的能量损失和振动。.
The single shaft shredder cutter shaft adopts advanced machining techniques during production. The blades mounted on the shaft use high-quality imported tool steels such as D2 or DC53, which offer superior hardness, toughness, and wear resistance. These blades maintain sharpness over extended use, providing consistent shredding performance even when processing tough materials.
推料系统对被撕碎的材料施加持续的压力，确保高效喂料和刀片的稳定接触。推料机构采用了先进的密封系统，可防止物料从粉碎室中漏出，从而提高安全性和操作清洁度。.
The screen mesh is a vital component that controls the final particle size of shredded material. It is available in various sizes, typically ranging from 30mm to 100mm, and can be tailored to meet specific customer demands. Made from hardened steel, the screen offers excellent abrasion resistance, ensuring longevity despite constant exposure to friction and impact.
单轴碎纸机的碎纸效果
产品参数
| 模型 | FTSS-600 | FTSS-800 | FTSS-1000 |
| 尺寸（毫米） | 1780*1290*1690 | 2670*1760*2090 | 2670*1960*2090 |
| 料斗开口（毫米） | 1200*1090 | 1500*1430 | 1420*1700 |
| 卸料高度（毫米） | 480 | 560 | 560 |
| 旋转尺寸（毫米） | Φ225 | Φ285 | Φ395 |
| 转速（转/分） | 80 | 80 | 80 |
| 刀具数量（PVC） | 23+4 | 35+4 | 45+4 |
| 固定刀数量（PVC） | 2+2 | 2+2 | 2+2 |
| 工作直径（毫米） | 600 | 800 | 1000 |
| 料斗容积（升） | 760 | 1500 | 1760 |
| 屏幕尺寸（毫米） | Φ40 | Φ40 | Φ40 |
| 主功率（千瓦） | 18.5 | 37 | 45 |
| 液压功率（千瓦） | 2.5 | 3.75 | 3.75 |
| 重量（千克） | 约 1750 | 约 4200 | 约 4250 |
实际照片
Frequently Asked Questions
- Why is the capacity of a single shaft shredder lower than that of a double shaft shredder?
A single shaft shredder has a different structure and shredding principle. It usually uses one motor with limited torque and processes materials by cutting and scraping, so the capacity is generally lower than that of a double shaft machine. A single shaft plastic shredder is more suitable for large plastic blocks and soft materials.
- Can a single shaft shredder process solid waste?
It is not recommended to use a single shaft shredder for mixed solid waste. Solid waste may contain metal or hard contaminants, which can damage the blades of a single shaft plastic shredder.
- Can a single shaft shredder be customized with a 10 mm screen?
Normally, the output size of a single shaft shredder is about 30–40 mm. The smallest customizable screen is usually around 20 mm. Screens below 20 mm may reduce discharge efficiency.
- What should I consider when buying a single shaft shredder for sale?
When choosing a single shaft shredder for sale, consider the material type, material size, required capacity, and final output size to ensure the machine matches the recycling application.
